Corrosion Resistant 16 Wire Stainless Steel Filter Bag Cage Used In Metallurgy, Power Generation
Influencing factors
(1) Influence of the size of the dust bag cage: In the geometric size of the dust bag cage, the diameter of the dust bag cage, the gas inlet, and the shape and size of the exhaust pipe are important influencing factors.
(2) The influence of gas parameters on the performance of the dust bag cage: including the influence of gas flow, the influence of gas dust concentration, the influence of gas moisture content, the influence of gas density, viscosity, pressure, temperature, etc.
(3) The influence of the physical properties of dust on the dust bag cage
(4) The influence of the roughness of the inner wall of the dust removal bag cage: the dust particles concentrated near the wall will cause swirling flow due to the rough surface, so that some dust particles will be thrown into the rising airflow and enter the exhaust pipe, reducing the dust removal efficiency.
The production types of Dust Collector Filter Cage are:
Shape:
(External filter type) (Oval, Rhombus)
envelope type
Multi-section frame (elliptical multi-section frame. Round bag multi-section frame (insert type, chuck type))
Finished frames (frames with venturi tubes. Plastic bags, frames packed in iron frames. Neatly arranged diamond-shaped frames)
Specification
Round, elliptical, flat, envelope, trapezoidal, star, spring, and other types of dust removal skeletons can be customized according to customer requirements.
Raw materials: high-quality low-carbon steel wire, galvanized steel wire, stainless steel wire, etc.
Surface treatment: galvanized, sprayed, anti-corrosion treatment, surface silicone spraying, etc. The surface silicone coating is especially suitable for the dust collector application of large generator sets.
Specifications
| Types: | Round Style/Flat Style/Envelope Style/ Special Style |
| Number Of Wires: | 8/10/12/16/20/24 vertical wires(usually) |
| Ring Space: | Ring spacing standard is 6 inch or 8 inch.(15.24cm or 20.32cm) |
| Cage Diameter: | Cage diameters range from 4 inch to 8 inch (100mm to 200mm) |
| Wire thickness: | Wire thickness ranges are 2mm to 5mm |
| Material: | Carbon Stee, Galvanized Steel, Stainless Steel |
| Finishment: | Epoxy, PVC vinyl coating |
| Packaging: | Cages are packed in custom designed cartons |
| Usage: | Dust from factory of mine, wood,Cement, chemical, medicine, dying,Paint, plastic, food & other industry,such as coal fired power stations, Steel Power station, Cement industry, Paper industry & other Industrial Segments. |
| Advantages: | 1.no corrosion 2.no damage 3.3-5 times longer life than other bag Cage with steel |
| 4. economical maintenance(almost no Maintenance required) |
| 5.prominent effect in removing dust from Filter by pulsing 6.easy to install |
| 7.no ventury installation required |
Standard Technical Data
| Round Style | Diameter(mm) | Bag Diameter(mm) | Length(mm) |
| 115 | 120 | 2000,2400 2800, |
| 3200,3600,4000, |
| 125 | 130 | 4400,4800,5200, |
| 147 | 152 | 560,060,007,000 |
| 195 | 200 | |
| Flat Style | Perimeter | Bag Perimeter | Length(mm) |
| 800 | 800 | 2000 3000 4000 |
| 5000 6000 |
| 900 | 900 | |
| Envelope Style | Length Width Thickness | Bag Length Width Thickness |
| 1500X750x25mm | 1500X750x25mm |
Why choose us?
1. Factory Experience: We are an experienced manufacturer with complete production lines and professional production equipment.
2. Quality assurance: We always strictly implement the quality management system, run through every detail of production, and be responsible for the products required by customers.
3. One-stop purchasing: We provide one-stop purchasing of filtration products to meet the different needs of global customers.
4. Other advantages: We respond quickly within 12 hours, provide efficient and high-quality services and competitive prices.
Filter Bag Cage Production Process:
Our factory:
Our Certificate:
More details, pls feel free to contact us, Thanks
